| Table travel (X,Y,Z) | mm | 1800（2000）×600×900 |
| Table size | mm | 2500×575 |
| Min. distance from hor. spindle axis to worktable surface | mm | 30 |
| Min. distance from vertical spindle nose to worktable surface | mm | 49 |
| Distance from vertical spindle axis to column guideway | mm | 110 |
| Number/Width/Distance of T-slot | mm | 3-22-152 |
| Spindle taper | | ISO50 |
| Spindle speed range | rpm | 40-1200 |
| Longitudinal, transverse feed speed range stepless | mm/min | 20-2200 |
| Spindle motor power | kW | 11 |
| Max. load of worktable | kg | 3000 |
| Overall dimension（L×W×H） | mm | 4300×3200×3300 |
| Machine weight | kg | 10000 |
