| Table travel (X,Y,Z) | mm | 1500×550 |
| Table size | mm | 2100×500 |
| Max. load of table （equally） | kg | 2000 |
| Number/Width/Distance of T-slot | mm | 4-20-100 |
| rapid feed speed | mm/min | 6000/6000/3000 |
| Spindle speed | rpm | 35-1345 |
| Distance from spindle nose to table surface | mm | 0-650 |
| Distance from spindle axis to column guideway | mm | 610 |
| Spindle motor power | kW | 7.5 |
| Feed motor power | kw | 2.5 |
| Coolant motor power | W | 550 |
| tool weight | kg | 20 |
| Positioning accuracy | mm | 0.025 |
| Repeat positioning accuracy | mm | 0.015 |
| Machine weight | kg | 7300 |
| Overall dimension (L x W x H) | mm | 3650×2380×2750 |
