| Spindle diameter | mm | Ф110 |
| Longitudinal travel of table | mm | 1350 |
| Transverse travel of table | mm | 1250 |
| Headstock vertical travel | mm | 900 |
| Spindle axial travel | mm | 550 |
| Max. boring diameter | mm | Ф240 |
| Max. drilling diameter | mm | 50 |
| Table size | mm | 1320×1010 |
| Max. load of table | kg | 2500 |
| Distance from spindle nose to table surface | mm | 5-905 |
| Feeding range | mm/min | 0.2-330 |
| Spindle speed range | rpm | 12-1100 |
| Facing head speed range | rpm | 4-130 |
| Spindle motor power | kw | 43419 |
| Positioning accuracy | mm | 0.02/500 |
| Repeat positioning accuracy | mm | 0.014/500 |
| Overall dimension | mm | 5375×2995×3035 |
| Machine weight | kg | 12300 |
