| X-axis travel | mm | 3000 |
| Y-axis travel | mm | 2000 |
| Z-axis travel | mm | 500 |
| Worktable size | mm | 2000×3000 |
| Max. load of worktable | kg | 6000 |
| Number /Width/Distance of T-slot | qty | 9/28/200 |
| Distance between the two colums | mm | 2400 |
| Distance from spindle nose to worktable surface | mm | 150-650 |
| Spindle taper | | ISONO.50 |
| Feed speed | mm/min | 4000 |
| Rapid speed X,Yaxis | mm/min | 12000 |
| | | |
| Z axis | | 8000 |
| Spindle moter power (continuous /S6-60% ) | mm/min | 12 |
| Spindle speed | kw | 10-3000 |
| Positioning accuracy | rpm | ±0.005/300 JIS |
| Repeat positioning accuracy | mm | ±0.003/1000 JIS |
| Machine weight | mm | 20000 |
