| X-axis travel | mm | 8500 | 10500 |
| Y-axis travel | mm | 450+800 | 4500+800 |
| Z-axis travel | mm | 1200 | 1200 |
| W-axis travel | mm | 2250 | 2250 |
| Worktable size | mm | 3000*8000 | 3000*8000 |
| Max. load of worktable | t | 60 | 60 |
| Number /Width/Distance of T-slot | qty | 32/36/250 | 40/36/250 |
| Distance between the two colums | mm | 3600 | 3600 |
| Distance from spindle nose to worktable surface | mm | 150-3000 | 150-3000 |
| Spindle taper | | BT50 | BT50 |
| Feed speed X,Y,Z axis | mm/min | 6000/6000/6000 | 6000/6000/6000 |
| W axis | mm/min | 2000 | 2000 |
| Rapid speed X,Y,Z axis | mm/min | 10000/10000/10000 | 10000/10000/10000 |
| W axis | mm/min | 2000 | 2000 |
| Spindle moter power | kw | 45/55 | 45/55 |
| Spindle speed | rpm | 30-3000 | 30-3000 |
| Positioning accuracy X,Y,Z | mm | ±0.003/300JIS | ±0.003/300JIS |
| Repeat positioning accuracy X,Y,Z | mm | ±0.003/1000JIS | ±0.003/1000JIS |
| Overall dimension | mm | 26000*10000*9300 | 26000*10000*9300 |
| Machine weight | kg | 205000 | 205000 |
