| Table travel (X,Y,Z) | mm | 800×350×280 | 920×380×350 |
| Table size | mm | 1320×320 | 1700×400 |
| Max. load of table | kg | 320 | 500 |
| Number/Width/Distance of table T-slot | mm | 3-18-70 | 3-18-90 |
| Distance from spindle axis to table | mm | 20~370 | 30-410 |
| Distance from column vertical guideway | mm | 225~505 | 275-625 |
| | | |
| to the center of table | | | |
| Rapid feed speed | mm/min | 6000/3000/6000 | 6000/3000/6000 |
| Spindle speed | rpm | 30-1500 | 30-1500 |
| Spindle motor power | kW | 7.5 | 11 |
| Longitudinal, transverse feed motor torque | N.m | 12 | 12 |
| Overall dimension | mm | 1929×2055×1960 | 1929×2055×1960 |
| Machine weight | kg | 2800 | 3850 |
