| Capacity | Max. swing dia. over bed | mm | Φ450 |
| Max. swing dia. over slides | mm | φ280 |
| Max. turning dia. | mm | φ285 |
| Max. workpiece length | mm | 500 |
| Spindle | Hydraulic chuck diameter | mm | Φ169 |
| Spindle nose | mm | A2-5 （GB/T5900.1） |
| Spindle speed | r/min | 80-8000 |
| Main motor power(cont/30min) | kw | 15/18.7 |
| Tailstock | Quill diameter/travel | mm | Φ70/80 |
| Center taper | | MT No.4 |
| Turret | Tool section (turning/boring) | mm | 20×20/Φ32 |
| Carriage | Slant degree | | 45° |
| X/Z-axis travel | mm | 165/510 |
| X/Z-axis rapid traverse | m/min | 42/42 |
| X/Z-axis servo motor torque | Nm | 10.3/14.7 |
| X/Z-axis ball screw diameter | mm | Φ32/Φ40 |
| Other | Power source | kVA | 40 |
| Dimension(L×W×H) | mm | 3740×1780×1930 (side-mounted chip conveyer) |
| Gross weight | mm | 4500 |
