| Max. swing over bed (mm) | φ400 | Φ500 |
| Max. swing over slide (mm) | φ200 | Φ280 |
| Max. turning dia. (mm) | φ400/350 * | φ500/350 * |
| Max. work length (mm) | 710/620; 960/870; 1460/1370; 1960/1870;2960/2870 | 710/620; 960/870; 1460/1370; 1960/1870;2960/2870 |
| Max. turning length (mm) | 570/500; 820/750; 1320/1250; 1820/1750;2820/2750 | 570/500; 820/750; 1320/1250; 1820/1750;2820/2750 |
| Spindle taper hole (mm) | φ77 | φ77 |
| Spindle nose | ISO702/ⅠA2-8 | |
| Spindle speed (r/min) | 3 gear stepless 21-1620 | |
| H:162-1620 M:66-660 L:21-210 | |
| Taper hole of spindle | Metric 1:20 | |
| Max. output torque of spindle (N.m) | 800 | |
| Max. rapid traverse (m/min) | X-axis: 6(See OPERATOR’S MANUAL---ELECTRICAL PARTS for details) | |
| Z-axis: 8(See OPERATOR’S MANUAL---ELECTRICAL PARTS for details) | |
| Pitch of screw (mm) | X direction: 5 Z direction: 6 | |
| Capacity of turret | 4(standard)/6(optional) | |
| Width of tool block(mm) | 162X162 | 200X200 |
| Max. permissible tool section (mm ×mm) | 25×25 | 25×25 |
| Travel of turret (mm) | X direction: 300/235（6-station） | X direction: 300/235（6-station） |
| Z direction: 600/850/1350/1850/2850 | Z direction: 600/850/1350/1850/2850 |
| Dia. of tailstock quill (mm) | φ75（φ80 hyd. tailstock） | φ75（φ80 hyd. tailstock） |
| Taper of tailstock quill (MT No.) | MT No.5（MT No.3 hyd. tailstock with live spindle） | MT No.5（MT No.3 hyd. tailstock with live spindle） |
| Max. travel of tailstock quill(mm) | 150（130 hydraulic tailstock） | 150（130 hydraulic tailstock） |
| Cross travel of tailstock (mm) | ±15 | ±15 |
| Main motor | 7.5kW frequency inverting motor | 7.5kW frequency inverting motor |
| Dimension (L×W×H) | 750 2450×1450×1670 | 750 2450×1450×1670 |
| mm× mm× mm | 1000 2700×1450×1670 | 1000 2700×1450×1670 |
| 1500 3200×1450×1670 | 1500 3200×1450×1670 |
| 2000 3700×1450×1670 | 2000 3700×1450×1670 |
| 3000 4700×1500×1690 | 3000 4700×1500×1690 |
| Packing size (L×W×H) | 750 308(325) **×186×225 | 750 308(325) **×186×225 |
| cm× cm× cm | 1000 313(330) **×186×225 | 1000 313(330) **×186×225 |
| 1500 363(380) **×186×225 | 1500 363(380) **×186×225 |
| 2000 413(430) **×186×225 | 2000 413(430) **×186×225 |
| 3000 504(536) **×186×230 | 3000 504(536) **×186×230 |
