| Capacity | Max. swing dia. over bed | mm | Φ360 | Φ360 |
| Distance between centers | mm | 750/690(6-station)/650* | 750/690(6-station)/650* |
| Max. swing dia. over slides | mm | Φ180 (4/6-station)/Φ105 (comb type tool rest) | Φ180 (4/6-station)/Φ105 (comb type tool rest) |
| Max. turning length | mm | 600/540(6-station)/500* | 600/540(6-station)/500* |
| Spindle | Spindle thru-hole | mm | Φ57 | Φ57 |
| spindle nose | no | D type No.6 manual chuck | D type No.6 manual chuck |
| | | ISO702/I A2-5 6″ hyd. chuck | ISO702/I A2-5 6″ hyd. chuck |
| | | ISO702/I A2-6 8″ hyd. chuck | ISO702/I A2-6 8″ hyd. chuck |
| Rotation sped of spindle | r/min | 140-3000(infinite variable speed) | 140-3000(infinite variable speed) |
| Spindle motor power | KW | 5.5 | 5.5/7.5 |
| Tailstock | Dia./ travel of quill | mm | Φ55/120 (100 hyd. tailstock); Φ75/150* (130* hyd. tailstock) | Φ55/120 (100 hyd. tailstock); Φ75/150* (130* hyd. tailstock) |
| Taper of center | mm | ISO702/I A2-6 8″ hyd. chuck | ISO702/I A2-6 8″ hyd. chuck |
| Turret | Dia. of boring tool (mm) | | 20×20 | 20×20 |
| Tool section (mm) | mm | Φ32 | Φ32 |
| Other | Power source | kVA | 12 kVA | 12 kVA |
| Belt of main motor | | 3V-670 | SPZ1987 |
| Dimension (L×W×H) | mm | 2150×1260×1600 | 2150×1260×1600 |
| Total weight | kg | 1700 | 1700 |
| Max. machining weight (supported by tailstock center) | Kg | 550(Ф200 manual 3-jaw chuck), 360(6 hyd. chuck), 550(8 hyd. chuck) | 550(Ф200 manual 3-jaw chuck), 360(6 hyd. chuck), 550(8 hyd. chuck) |
