| MAIN PARAMETER | Max swing diameter over bed | mm | φ500 |
| Max swing diameter over cross slide | mm | φ280 |
| Max workpiece length | mm | 750/1000/1500/2000 |
| Max cutting length | mm | 680/930/1430/1930 |
| Max turning diameter | mm | φ500 |
| Spindle center height | mm | 250 |
| Bed guideway width | mm | 400 |
| SPINDLE | Spindle motor power | kW | 7.5/11 |
| Spindle bore | mm | φ82 |
| Chuck size | mm | φ250 |
| Taper of spindle bore | | Front end φ90 1:20 |
| Type of spindle nose | | D8 |
| Spindle speed ranges | r/min | 7-2200 |
| TAILSTOCK | Diameter of tailstock quill | mm | φ75 |
| Travel of tailstock quill | mm | 150 |
| Taper of tailstock quill | | No.5 MT |
| TOOLPOST | Tool shank size (Vertical 4-position) | mm | 25*25 |
| ACCURACY | X/Z axis positioning accuracy | mm | 0.018/0.021 (750) |
| 0.024 (1000)、0.026 (1500/2000) |
| X/Z axis repeatability accuracy | mm | 0.006/0.008 (750) |
| 0.011 (1000)、0.014 (1500/2000) |
