| Worktable size | mm | 1000*500 | |
| TABLE | T-Slot (Quantity*Width*Distance) | mm | 5*18*100 | |
| Max load of worktable | kg | 500 | |
| TRAVEL | X/Y/Z axis travel | mm | 860/510/560 | |
| X/Y/Z axis guideway type | mm | Linear guideway | |
| Distance from spindle center to column | mm | 607 | |
| Distance from spindle nose to table | mm | 145~705 | |
| FEED RATE | Rapid traverse of X/Y/Z axis | m/min | 36/36/30 | |
| Cutting feed rate | mm/min | 0~10000 | |
| SPINDLE | Max spindle speed | r/min | 12000 | |
| Spindle taper | | No.40 (7:24) | |
|
| ATC system | Tool magazine capacity | | 24T/Arm | |
|
| Tool shank type | | BT40 | |
|
| Max. tool weight | kg | 8 | |
| Max. tool diameter (w/o adjacent tools) | mm | 24T: φ78/155 | |
| Max.tool length | mm | 300 | |
| Time of tool change (T-T) | s | 24T: 2.5 | |
| ACCURACY | X/Y/Z axis positioning accuracy | mm | 0.008/0.008/0.008 | |
| X/Y/Z axis repeatability accuracy | mm | 0.005/0.005/0.005 | |
| CONTROL SYSTEM | Controller | | GSK/SIEMENS/FANUC | |
|
