| Machining range | | | |
| X/Y/Z -axis travel | mm | 4700/2600/1000 | 6300/2500/1100 |
| Distance from the spindle nose to table surface (optional) | mm | 600-1600（Optional） | 150-1250(Vertical） |
| | | 180-1280（Horizontal） |
| Distance between the two columns | mm | 2600 | 2600 |
| Table specifications | | | |
| Table size :(L/W) | mm | 4500/2000 | 6000×2000 |
| T-slot size (Number/Width/Distance) | | 9/28/200 | 9/28/225 |
| Max. load of table | kg | 13500 | 20000 |
| Spindle specifications | | | |
| Spindle speed | rpm | 10-3200 | 30-3000 |
| Spindle motor power | kw | 18.5/22 | 18.5/22 |
| Taper of spindle bore | | BT50 | BT50 |
| Max. output torque spindle | Nm | 560 | 280 |
| Feeding system | | | |
| Axis rapid moving speed X/Y/Z | mm/min | 12000/12000/8000 | 12000/12000/8000 |
| Cutting feed speed X/Y/Z | mm/min | 1-4000/1-4000/1-2000 | 1-4000/1-4000/1-2000 |
| Accuracy | | | |
| X/Y/Z Positioning accuracy | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| X/Y/Z Repositioning accuracy | mm | ±0.003/1000 JIS | ±0.003/1000 JIS |
| Numerical control system | | | |
| Model | | FANUC 0i-MD | FANUC 0i-MD |
| The total number of control axes | Axes | 4 | 4 |
| Accessory milling head | | | |
| Indexing mode | | automatic indexing/terminal gear plate positioning / 5 ° degree | automatic indexing/terminal gear plate positioning / 5 ° degree |
| Indexing accuracy | | ±3second | ±3second |
| Milling head clamp/ unclamp | | oil pressure control | oil pressure control |
| Machine floor area and weight | | | |
| Machine floor area (L×W×H) | mm | 12670/6080/5480 | 16000×7500×5600 |
| Machine weight | kg | 50000 | 58000 |
