| Specification | Units | X2010 | X2012 | X2016 | |
|---|---|---|---|---|---|
| Table effective size | Length | mm | 4000/6000/8000 | 3000/4000/6000 | 3000/4000/6000 |
| Width | mm | 800 | 1000 | 1200 | |
| Number/width/distance of table T-slot | mm | 5-28-160 | 5-28-160 | 5-28-225 | |
| Max. load of table | kg | 5000/6000/8000 | 6000/8000/10000 | 10000/12000/15000 | |
| Max. machining workpiece | Length | mm | 3000/4000/6000 | 3000/4000/6000 | 4000/6000/8000 |
| size | Width | mm | 1000 | 1250 | 1600 |
| Height | mm | 800 | 1000 | 1250 | |
| Gantry width | mm | 1100 | 1350 | 1700 | |
| Milling head | Power | kW | 5.5 | 5.5 | 7.5 |
| Taper of | ISO50 | ISO50 | ISO50 | ||
| spindle hole | |||||
| Range of | r/min | 140-803 | 140-803 | 97-675 | |
| speed | |||||
| Power | kw | 5.5/5.5/7.5 | 5.5/5.5/7.5 | 7.5/11/11 | |
| Table feed speed | mm/min | 60-800 | 60-800 | 60-800 | |
| Lifting speed of cross beam | mm/min | 570 | 570 | 570 | |
| Overall dimension | Length | mm | 8000/10000/14000 | 8000/10000/14000 | 10600/14600/18600 |
| Length | mm | 3300 | 3570 | 4050 | |
| Height | mm | 2700 | 2900 | 3450 | |
| Weight | t | 14/17/21 | 16/20/24 | 26/31/36 |
