| Table size | mm | 1800×630 |
| Distance from spindle axis to table surface | mm | 50-700 |
| Distance from spindle nose to datum T-slot center of table | mm | 240-400 |
| Distance from spindle axis to column guideway | mm | 160 |
| Travel of table | mm | 1800 |
| Travel of headstock | mm | 650 |
| Range of speed | r/min | 32-1000 |
| Number/Width/Distance of T-slot | mm | 5-22-125 |
| Feed speed of headstock | mm/min | 232 |
| Table rapid feed speed | mm/min | 3475 |
| Main motor power | kw | 7.5 |
| Table feed motor power | kw | 2.2 |
| Max. load of worktable | kg | 2500 |
| Overall dimension | mm | 4640×1600×2100 |
| Machine weight | kg | 6500 |
