| Table travel (X,Y,Z) | mm | 1050×900×900 | 1050×900×900 | 800×650×700 |
| Table size | mm | 630×630 | 500X500 | 320×320 |
| Max. load of table （equally） | kg | 1300 | 600 | 1000 |
| Worktable indexing | | 1°×360° | 1°×360° | 1°×360° |
| rapid feed speed | m/min | 36 | 32 | 15/10/15 |
| Spindle speed | rpm | 35-6000 | 35-6000 | 2400/6000 |
| Main motor power | kW | 18.5/22 | 18.5/22 | 11/15 |
| Tool magazine capability | qty | 40（Chain type） | 24(Arm type） | 24 |
| tool weight | kg | 20 | 15 | 15 |
| Positioning accuracy (X,Y,Z) | mm | ±0.005/300 JIS | ±0.005/300 JIS | ±0.0025 JIS |
| Repeat positioning accuracy (X,Y,Z) | mm | ±0.003/300 JIS | ±0.003/300 JIS | ±0.0015 JIS |
| Machine weight | kg | 18000 | 10000 | 8500 |
| Overall dimension (L x W x H) | mm | | | 2900×3200×2650 |
