| Table travel (X/Y) | mm | 1300/470 | 1500/470 |
| Table size | mm | 1635×500 | 2000×500 |
| “T”Slot（No./Width） | mm | 43238 | 43238 |
| Distance of “T” slot | mm | 80 | 80 |
| Distance from spindle nose to table surface | mm | 40mm~510 | 40mm~510 |
| Distance from spindle axis to column | mm | 70~670 | 70~670 |
| guideway | | | |
| Spindle speed（frequency） | r.p.m | 53-1800 | 53-1800 |
| table feed speed(Longitudinal) | mm/min | 2500 | 2500 |
| table feed speed(Vertical) | mm/min | 1200 | 1200 |
| Main motor power | kw | 7.5 | 7.5 |
| Feeding motor power X、Y、Z | N/m | 18、18、22 | 18、18、22 |
| Overall dimension | mm | 2000×2100×2200 | 2000×2100×2200 |
| Machine weight | kg | 3500 | 3500 |
