| Table size | mm | 1650×360 |
| Longitudinal/traverse/vertical travel | mm | 1300/320/420 |
| T-slot | mm | 3/14/95 |
| Spindle taper | mm | 7:24 ISO50 |
| Spindle speed | rpm | H： 12 steps 58—1800 V：12 steps 60—1750 |
| Distance from horizontal axis to table surface | mm | 0—420 |
| distance from spindle nose to table surface | HP | 0—420 |
| distance from table center to column surface | mm | 230--550 |
| table swivel degree | | ±35º |
| table feed speed | mm/min | Longitudinal/cross: 25～800 |
| | Vertical：8-267 |
| | Rapid： Longitudinal/traverse1200 Vertical 400 |
| Feed servo motor | kw | 1.8，11.5N·M |
| Horizontal | kw | 5.5(H),4(V) |
| Overall size（L×W×H） | mm | 2550×2161×2102 |
| Net weight | kg | 2850 |
