| Table travel (X,Y,Z) | mm | 1630×550 |
| Table size | mm | 2400×650 |
| Number/Width/Distance of T-slot | mm | 5-22-100 |
| Vertical travel of horizontal spindle | mm | 800 |
| Vertical travel of vertical spindle | mm | 800 |
| Min. distance from hor. spindle axis to table | mm | 20 |
| Spindle taper | | (V)ISO50，(H)ISO50 |
| Spindle speed range | rpm | (V)19-860，(H)19-860 |
| Longitudinal, transverse feed speed range stepless | mm/min | 20-2200 |
| Longitudinal, transverse rapid feed speed range | mm/min | 2200 |
| Spindle motor power | kW | (V)11，(H)11 |
| Feed motor power | kW | 4.4 |
| Max. load of worktable | kg | 3000 |
| Overall dimension（L×W×H） | mm | 4100×3700×4250 |
| Machine weight | kg | 17000 |
