| Table travel (X,Y,Z) | mm | 1000×600×550 | 1000×600×550 |
| Table size | mm | 1100×600 | 1100×600 |
| Max. load of table | kg | 600 | 600 |
| Distance from spindle nose to table surface | mm | 150-700 | 150-700 |
| Distance from spindle axis to column guideway | mm | 660 | 660 |
| rapid feed speed | mm/min | 24、24、18 | 30、30、24 |
| Spindle speed | rpm | 60-8000 | 60-8000 |
| Main motor power | kW | 7.5/11 | 7.5/11 |
| Max. weight of tool | kg | 8 | 8 |
| Max. dimension of tool | mm | Φ150×350 | Φ150×350 |
| Positioning accuracy | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| Repeat positioning accuracy | mm | ±0.003/300 JIS | ±0.003/300 JIS |
| Min. time of tool change | sec | 1.4 | 1.4 |
| Machine weight | kg | 2800×2200×2600 | 2800×2200×2600 |
| Overall dimension (L x W x H) | mm | 6320 | 6520 |
