| Table travel (X,Y,Z) | mm | 1200×600×600 |
| Table size | mm | 1200×620 |
| Number/Width/Distance of T-slot | mm | 5-18-115 |
| Max. load of table | kg | 1000 |
| Distance from spindle nose to table surface | mm | 150-750 |
| Distance from spindle axis to column guideway | mm | 660 |
| Rapid feed speed | m/min | 24 、24、18/30、30、24 |
| Feed speed | mm/min | 2.5-6000 |
| Taper of spindle | | BT50 |
| Spindle moter power | kw | Ac servo 11/15 |
| Spindle speed | rpm | 40-4000 |
| Positioning accuracy X,Y,Z | mm | ±0.005/300 JIS |
| Repeat positioning accuracy X,Y,Z | mm | ±0.003/300 JIS |
| Overall dimension | mm | 3250×2500×2600 |
| Machine weight | kg | 810 |
