| Table travel (X,Y,Z) | mm | 1200×600×600 | 1400×600×600 |
| Worktable size | mm | 1220×620 | 1400×620 |
| Max. load of worktable | kg | 1000 | 1000 |
| Number /Width/Distance of T-slot | qty | 5-18-115 | 5-18-115 |
| Distance between the two colums | mm | 660 | 660 |
| Distance from spindle nose to worktable surface | mm | 150-750 | 150-750 |
| Max. weight of tool | kg | 15 | 15 |
| Max. dimension of tool | mm | Φ150×300 | Φ150×300 |
| Taper of spindle | | BT40 | BT40 |
| Spindle moter power | kw | （AC servo）7.5/11 | （AC servo）7.5/11 |
| Spindle speed | rpm | 40-6000 | 40-6000 |
| Positioning accuracy X,Y,Z | mm | ±0.005／300 JIS | ±0.005／300 JIS |
| Repeat positioning accuracy X,Y,Z | mm | ±0.003/300 JIS | ±0.003/300 JIS |
| Overall dimension | mm | 3250×2500×2600 | 3250×2500×2600 |
| Machine weight | kg | 8200 | 8500 |
