| Table travel (X,Y,Z) | mm | 1600×850×700 | 1300×700×650 |
| Table size | mm | 1800×800 | 1400×710 |
| Max. load of worktable | kg | 2000 | 1000 |
| Number /Width/Distance of T-slot | mm | 5-22-150 | 5-18-152 |
| Distance from spindle nose to table surface | mm | 200-900 | 200-900 |
| Distance from spindle axis to column guideway | mm | 930 | 785 |
| Spindle taper | | BT50 | BT50 |
| Spindle moter power | kw | （AC servo）15/18.5 | 43419 |
| Spindle speed | rpm | 40-4500 | 40-6000 |
| Max. weight of tool | kg | 25 | 25 |
| Max. dimension of tool | mm | Φ220×400 | Φ220×400 |
| Positioning accuracy | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| Repeat positioning accuracy | mm | ±0.003/300 JIS | ±0.003/300 JIS |
| Overall dimension | mm | 4400×3400×3200 | 3700×3350×2890 |
| Machine weight | kg | 13000 | 11000 |
