| Table travel (X,Y,Z) | mm | 400×250×400 | 400×250×400 |
| Table size | mm | 600×250 | 600×250 |
| Number/Width/Distance of T-slot | mm | 3-14-75 | 3-14-75 |
| Distance from spindle nose to table surface | mm | 60-460 | 60-460 |
| Distance from spindle axis to column guideway | mm | 325 | 325 |
| Rapid feed speed | m/min | 6000 | 6000 |
| Spindle speed | rpm | 60-6000 | 60-6000 |
| Taper of spindle | | BT30 | BT30 |
| Spindle motor power | kW | (AC servo)3.7 | (AC servo)3.7 |
| Tool magazine capability | qty | 10 | |
| Max. weight of tool | kg | 5 | |
| Positioning accuracy (X,Y,Z) | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| Repeat positioning accuracy (X,Y,Z) | mm | ±0.003/300JIS | ±0.003/300JIS |
| Overall dimension | mm | 1650×1600×2000 | 1650×1600×2000 |
| Machine weight | kg | 2000 | 1800 |
