| Table travel (X,Y,Z) | mm | 620×350×500 | 620×350×500 |
| Table size | mm | 920×320 | 920×320 |
| Number/Width/Distance of T-slot | mm | 3-14-85 | 3-14-85 |
| Distance from spindle nose to table surface | mm | 100-600 | 100-600 |
| Distance from spindle axis to column guideway | mm | 395 | 395 |
| Rapid feed speed | m/min | 18000 | 18000 |
| Spindle speed | rpm | 60-6000 | 60-6000 |
| Feed speed | mm/min | 2.5-3000 | 2.5-3000 |
| Tool shank type | | BT40 | BT40 |
| Spindle motor power | kW | 5.5 | 5.5 |
| Tool magazine capability | qty | 16 | |
| Max. weight of tool | kg | 8 | |
| Positioning accuracy (X,Y,Z) | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| Repeat positioning accuracy (X,Y,Z) | mm | ±0.003/300 JIS | ±0.003/300 JIS |
| Overall dimension | mm | 2020×1970×2160 | 2020×1970×2160 |
| Machine weight | kg | 3200 | 3000 |
