| Table travel (X,Y,Z) | mm | 650×400×500 | 650×400×500 |
| Table size | mm | 900×400 | 900×400 |
| Max. load of table （equally） | kg | 400 | 400 |
| Number/Width/Distance of T-slot | mm | 3-18-130 | 3-18-130 |
| Distance from spindle nose to table surface | mm | 120-620 | 120-620 |
| Distance from spindle axis to column guideway | mm | 510 | 510 |
| Rapid feed speed | m/min | 30/30/24 | 30/30/24 |
| Spindle speed | rpm | 40-6000 | 60-6000 |
| Taper of spindle | | BT40 | BT40 |
| Main motor power | kW | 5.5 | 5.5 |
| Tool magazine capability | qty | 16 | |
| Max. weight of tool | kg | 8 | |
| Positioning accuracy (X,Y,Z) | mm | ±0.005/300 JIS | ±0.005/300 JIS |
| Repeat positioning accuracy (X,Y,Z) | mm | ±0.003/300 JIS | ±0.003/300 JIS |
| Overall dimension | mm | 2120×2150×2290 | 2120×2150×2290 |
| Machine weight | kg | 3600 | 3400 |
